Low Voltage Battery GLW-200
- 10.49 kWh
- 51.2V 200Ah
- LiFePO4
- Wall-mounted
Send us your load list and we size it.
Compact wall-mounted low-voltage LiFePO4 battery, 10.49 kWh per module, designed for space-constrained residential installations with wide inverter compatibility and full BMS protection.
Best for: Space-constrained homes that need storage on the wall rather than the floor
Key Specifications
Battery Parameters
| Battery Type | 51.2V 200Ah LiFePO4 |
|---|---|
| Rated Voltage | 51.2 V |
| Rated Capacity | 200 Ah |
| Rated Energy | 10.49 kWh |
| Voltage Range | 44.8 – 57.6 V |
Operational Parameters
| Charge / Discharge Current | 100 / 100 A |
|---|---|
| Charging Temperature | 0 ~ 55 ℃ |
| Discharge Temperature | -20 ~ 60 ℃ |
| Storage Temperature | -10 ~ 40 ℃ |
System Parameters
| Port Communication | RS485 / RS232 / CAN |
|---|---|
| Display | LED + LCD |
| Wireless Communication | WiFi / Bluetooth |
| Compatible Inverters | Growatt / Solis / Goodwe / Sol-Ark / SRNE / DEYE |
| Cycle Life | >6000 (0.5C @25℃, 90% DOD) |
| Design Lifespan | 15 years |
| Dimension (L×W×H) | 453 × 228 × 750 mm |
| Weight | 90.6 kg |
Certification
| Certificates | CE / EMC |
|---|---|
| Transportation | UN38.3 |
Where It Fits
- Retrofits onto an existing 51.2 V hybrid inverter
- Homes adding capacity module by module
- Small commercial sites with a three-phase hybrid inverter
- Installations where wall, rack or floor space is the constraint
Compatible Equipment
Growatt, Solis, GoodWe, Sol-Ark, SRNE and DEYE hybrid inverters, over RS485 / RS232 / CAN.
